2022 Polaris GENERAL XP 4 1000 Deluxe RIDE COMMAND Edition

2022 Polaris GENERAL XP 4 1000 Deluxe RIDE COMMAND Edition
Black Crystal
MSRP: $31,999.00
Manufacturer: Polaris
Condition: New



Troy Lee Designs and Polaris collaborated to drop a Limited Edition XP 4 1000 GENERAL featuring TLD’s® Signature Style and with Capability to Go Further, and Gear Hauling options for trail building tools and bikes with plenty of room still for the cooler.

XP is the world’s most capable crossover side-by-side with room for your crew and require leading technology and connectedness. Equipped with industry-exclusive RIDE COMMAND GPS Technology and Rockford Fosgate® Stage 3 audio tuned for the off-road. Standard features include 64” stance, 30” Pro Armor tires, high clearance A-arms and Walker Evans Velocity shocks, it will elevate your off-road experience and take you on adventures that break new ground.



Cylinders Displacement
Drive System Type
On-Demand True AWD/2WD/VersaTrac Turf Mode
Engine Braking System (EBS)
EDA: Engine Deceleration Assist
Engine Type
ProStar 1000 4-Stroke DOHC Twin Cylinder
Fuel System/Battery
Electronic Fuel Injection
100 HP
Transmission/Final Drive
Automatic PVT P/R/N/L/H


Bed Box Dimensions (L x W x H)
27.5 x 43.1 x 11.6 in (69.8 x 109 x 29.5 cm)
Box Capacity
600 lb (272 kg) Rear Dumping Box
Dry Weight
2,008 lb (911 kg)
Fuel Capacity
9.5 gal (35.9 L)
Ground Clearance
13.5 in (34.3 cm)
Hitch Towing Rating
1,500 lb (680 kg)
Hitch Type
Standard 2 in (5.08 cm) Receiver
Overall Vehicle Size (L x W x H)
150.2 x 64 x 77 in (381.5 x 162.56 cm x 195.59)
Payload Capacity
1,280 lb (580 kg)
Person Capacity
64” (162.56 cm)
115 in (292 cm)


Front/Rear Brakes
4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers
Parking Brake
Park In-Transmission


Cargo System
Lock & Ride
Electronic Power Steering
High Output EPS
Ingress / Egress
Half Doors Standard
Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet
LED Headlight w/ Accent & LED Taillights
Other Standard Features
POLARIS HD 4500 LB Winch w/ Synthetic Rope, Aluminum Fairlead & Rubber Isolator, Sport Low Profile Front Bumper, ProFit Sport Roof, Convex Rear View Mirror, Rockford Fosgate Stage 1 Audio
Seat Type
Bolstered Bucket Seats with Driver Seat Slider and Height Adjustable Seat Belts
Tilt Steering


Front Tires
30 x 10-15; Pro Armor Crawler XGF
Rear Tires
30 x 10-15; Pro Armor Crawler XG
15" Aluminum


Front Shocks
Walker Evans Velocity Series Shocks
Front Suspension
Long Travel, High Clearance Dual A-Arm with Stabilizer Bar, 14" (35.6 cm) Travel
Rear Shocks
Walker Evans Velocity Series Shocks
Rear Suspension
Long Travel, High Clearance Dual Arm IRS with Stabilizer Bar, 14" (35.6) Travel



  • GEARED TO TAKE IT ON There’s lots to get excited about when you’re running trails with your friends and family. XP 4 is designed to add even more excitement to the mix.
  • STAY ON TOP OF THE TRAIL XP 4 comes equipped with 15" aluminum racing wheels and 30" Pro Armor Tires to give you sure-footed traction and max strength so you can confidently take-on even the roughest terrain.
  • TACKLE THE TOUGHEST TERRAIN Climbing up rocky crawls and powering through rutted trails can be a blast. But bottoming-out can end a good time quick. XP 4 has 13.5” of ground clearance so you can float over obstacles that would make others stop in your tracks.
  • EQUIPPED TO ENDURE Epic adventure starts with strong foundations. XP 4 is purpose-built with the widest stance in the adventure side-by-side market to keep you stable around the twists and turns of your favorite trails.
  • EXTEND YOUR ADVENTURE Save some energy for after the ride with a machine engineered for all-day comfort. Rocks and ruts will seem smaller thanks to 16 positions of adjustment, while wide bolstered seats keep you upright and relaxed for long days on the trail.
  • ROCK YOUR FAVORITE PLAYLIST Bring all your favorite music along for the ride with off-road optimized and tuned Rockford Fosgate Stage 1 audio including PMX-2 head unit and two dash-mounted speakers.
  • CONTROL THE RIDE Enjoy comfort and improved control in rough terrain with Walker Evans Velocity Series shocks. High-performance coilover and internal bypass design offers a higher resistance to bottoming-out and a smooth all-day ride.
  • STAY CONNECTED TO THE TRAIL — AND YOUR GROUP Track the trail, share favorite routes and stay with your group with Ride Command Edityion trim, featuring a 7" touchscreen display with configurable vehicle diagnostics, Bluetooth, cameras, GPS and Rockford Fosgate Stage 3 audio tuned and optimized for off-road adventures. Also features integrated plow mode and winch auto-stop.
  • PREPARED TO GO ANYWHERE — AND DO ANYTHING No matter what the trail throws in your way, you’ll have everything you need to find a path through, out, and home with the most versatile adventure side-by-side in the world. After all, the right gear always matters.
  • THE POWER TO PULL-BEHIND Whether you need to haul firewood to camp, carry gear for a long stay in the wild, drag logs off the trail or pull a trailer full of toys, you can do it all with XP’s 1,500 lb tow capacity.
  • RECOVERY-READY PULLING POWER The all-new Polaris HD Plus 4,500-lb winch with new fairlead and upgraded synthetic rope will help you confidently clear downed logs, get out of tough situations or set your line up a steep climb.
  • HAUL MORE OF WHAT MATTERS Be prepared with all the essentials for a long day of adventuring. A 600 lb dumping cargo box gives you the versatility to haul all the gear you need for any adventure.

All inventory listed is subject to availability and prior sale. Manufacturer's Suggested Retail Price (MSRP) if shown for a vehicle excludes set-up, freight, taxes, title, licensing or other dealer charges, and is subject to change. Individual prices may vary. Please request a quote for specific pricing.
